EVDC UNTETHERED
EVDC PRO 22kW/32A Untethered Station
Designed for Faster, Cleaner, and More Reliable Installation
The EVDC PRO Post-Mounted Charger is engineered with installers in mind. The integrated pedestal design simplifies electrical connections, reduces installation time, and provides a professional finish for commercial and public charging deployments.
Bottom-Mounted Terminal Block Access
A dedicated terminal block located at the base of the pedestal provides easy access for electrical connections without requiring complex disassembly.
Pre-Engineered Pedestal Solution
The charger comes with a purpose-built 5 mm thick steel pedestal, eliminating the need for third-party mounting solutions.
Secure Ground Installation
The pedestal base includes a 300 mm x 300 mm mounting plate with four heavy-duty anchor screws for a secure and durable installation. Additional rubber grommets are included to protect wiring, improve cable routing, and ensure a clean finished installation.
Optimized for Commercial Deployment
With a compact 150 mm x 150 mm pedestal profile and a 1500 mm overall height, the EVDC PRO provides an ideal charging height.
Technical Specifications
| Specification | Details |
|---|---|
| Charging Type | Level 2 AC Charging |
| Installation | Post-Mounted / Freestanding |
| Connector | Type 2 Socket (IEC 62196-2) or SAE J1772 Type 2 |
| Configuration | Untethered or Tethered (6 m) |
| Power Output | 7.4 kW (1-Phase) / 22 kW (3-Phase) |
| Input Voltage | 230 V AC (1-Phase) / 400 V AC (3-Phase) |
| Charger Dimensions | 90 mm (D) × 330 mm (H) × 230 mm (W) |
| Connectivity | 4G SIM Card |
| Communication Protocol | OCPP Enabled |
| Enclosure Rating | IP54 |
| Operating Environment | Indoor & Outdoor |
| Pedestal Material | 5 mm Thick Steel |
| Pedestal Height | 1500 mm Overall Height |
| Pedestal Column Dimensions | 150 mm × 150 mm |
| Base Plate Dimensions | 300 mm × 300 mm |
| Electrical Connection | Bottom-Mounted Terminal Block |
| Installation Hardware | 4 Heavy-Duty Anchor Screws + Rubber Grommets |
| Construction | Vandal-Resistant Housing with Stainless Steel Glands |
| Cable Glands | Stainless Steel |
| Mounting | Ground/Post Mounted Installation |
| Monitoring | Real-Time Monitoring & Remote Diagnostics |
| Certifications | CE Certified & RoHS Compliant |
| Warranty | 3-Year Limited Warranty |
*3-Year Warranty and professional technical support.
